Navigator Series

Navigator Series | Portable Smart AC EV Charger (3.5KW/7KW/11KW)

Built for on-the-go EV owners, road trip enthusiasts, mobile charging service providers, and cross-regional fleet operators

✅ 3 power options: 3.5KW / 7KW / 11KW, with customizable power adjustment

✅ Full standard compatibility: GB/T, IEC 62196, SAE J1772, NACS (Tesla), covering global EV models

✅ Smart APP control: remote monitoring, charging scheduling, and dynamic energy balance

✅ Industrial-grade protection: IP65 dust & waterproof + IK10 impact resistance, suitable for harsh outdoor use

✅ Ultra-portable design: compact size with 5m cable, plug-and-charge anywhere without installation

Core Performance

Wide power range from 3.5KW to 11KW, maximum output current up to 32A/40A, meeting fast charging demands for different EV models

Global voltage adaptation: 220V±15% (GB/T), 230V±15% (IEC), 240V±15% (SAE/NACS), compatible with household and commercial grids worldwide

4 charging standard options: GB/T (Chinese standard), IEC 62196 (European standard), SAE J1772 (American standard), NACS (Tesla standard), no adaptor needed for most EVs

Adjustable current and scheduled charging function, helping users avoid peak electricity prices and reduce charging costs

Smart Charging Experience

2.8-inch high-definition display (300nit brightness) with clear real-time charging data, status indicators and fault alerts

Touch button + APP dual operation mode: simple local operation, or remote control/monitoring via Bluetooth/WIFI

Real-time dynamic energy balance function, automatically adjusting charging power to prevent grid overload and lower electricity bills

Easy maintenance design with modular structure, supporting remote OTA upgrade for function iteration

Reliability and Protection

Industrial-grade dual protection: IP65 dust and waterproof rating + IK10 impact resistance, resistant to rain, dust, collision and harsh outdoor environments

Full-range safety protection: overvoltage, undervoltage, lightning, overcurrent, over-temperature, leakage, and grounding protection

Wide operating temperature range: -25℃ to +50℃, full power charging available in extreme cold and high-temperature environments

Working humidity 5%-95% non-condensing, suitable for high-humidity coastal and rainy regions

Portability and Usability

Ultra-compact dimensions: 213×80×50mm, lightweight body for easy carrying and storage

Standard 5m charging cable, flexible to use in various parking scenarios, no fixed installation required

Plug-and-charge design, compatible with all standard household and commercial sockets, available for charging at home, parking lots, roadside, and travel destinations

Leakage protection type optional (AC/DC/AC+DC), meeting different regional safety standards

Certification and Commercial Support

Full global certifications: CE, FC, RoHS, ISO, compliant with major market access requirements worldwide

Customization support: adjustable cable length, custom brand LOGO, function configuration (WIFI/Bluetooth/APP), meeting personalized brand and scenario needs

Ideal for EV rental fleets, road trip service providers, and mobile charging operators, providing flexible and reliable mobile charging solutions

Full technical support and after-sales service system, ensuring stable operation for bulk deployment scenarios
